View In:   ArcGIS Online Map Viewer

Name: MSI Mine Subsidence Risk (Confirmed)

Display Field: ID

Type: Feature Layer

Geometry Type: esriGeometryPolygon

Description: <DIV STYLE="text-align:Left;"><DIV><DIV><P><SPAN>This layer represents areas in Pennsylvania that are known to have been undermined or are near an undermined area due to coal and/or clay mining activity in the general vicinity. These areas are currently considered susceptible to mine subsidence. Additionally, the layer includes locations beneath mined outcrops that may be vulnerable to mine water outbreaks.</SPAN></P><P><SPAN>Mining activity in these areas has been confirmed through a mine map depicting underground workings, a reference source indicating the area was mined, or a subsidence investigation determining the area was mined.</SPAN></P><P><SPAN>The Department recommends Mine Subsidence Insurance coverage for any structures located within these areas, provided the structure meets other program requirements. More information is available at: www.dep.pa.gov/msi.</SPAN></P><P><SPAN>This layer was developed for use in the MSI Risk Webmap: https://gis.dep.pa.gov/msiRisk/.</SPAN></P></DIV></DIV></DIV>

Copyright Text: Commonwealth of Pennsylvania, Department of Environmental Protection, Mine Subsidence Insurance Program

Default Visibility: true

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 3000000

Max Scale: 5000

Supports Advanced Queries: true

Supports Statistics: true

Use Standardized Queries: true

Supports ValidateSQL: true

Supports Calculate: true

Extent:

XMin: -8963363.0912
YMin: 4825431.5716
XMax: -8396812.4737
YMax: 5116497.9988
Spatial Reference: 102100  (3857)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSFSSolid
Color: [204, 204, 204, 255]
Outline:
N/A
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: true
Supports Returning Geometry Centroid: false

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field:

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID, editable: false, nullable: false, defaultValue: null, modelName: OBJECTID )
• ID ( type: esriFieldTypeInteger, alias: ID, editable: true, nullable: true, defaultValue: null, modelName: ID )
• DESCRIPTION ( type: esriFieldTypeString, alias: DESCRIPTION, editable: true, nullable: true, length: 255, defaultValue: null, modelName: DESCRIPTION )
• Shape__Area ( type: esriFieldTypeDouble, alias: SHAPE.AREA, editable: false, nullable: false, defaultValue: null, modelName: SHAPE.AREA )
• Shape__Length ( type: esriFieldTypeDouble, alias: SHAPE.LEN, editable: false, nullable: false, defaultValue: null, modelName: SHAPE.LEN )

Templates:

• Name: MSI Mine Subsidence Risk (Confirmed)
  Description:
  Prototype:
  DESCRIPTION: null
  ID: null

  Drawing Tool: esriFeatureEditToolPolygon

Capabilities: Query

Sync Can Return Changes: false

Is Data Versioned: false

Supports Rollback On Failure: true

Supports ApplyEdits With Global Ids: false

Supports Query With Historic Moment: false

Supports Coordinates Quantization: true

Supported Operations:   Query   Query Attachments   Calculate   Validate SQL   Generate Renderer   Return Updates   Iteminfo   Thumbnail   Metadata
